Excavator arm for tractor, HADES TA250 PRO
![Tractor-mounted mini excavator GRAECUS HADES TA250 PRO, 15–45 HP [1]](https://op.gomagcdn.ro/domains/uneltisimo.ro/files/product/original/brat-excavator-pentru-tractor-translatie-mecanica-hades-ta250-pro-378735.png "Tractor-mounted mini excavator GRAECUS HADES TA250 PRO, 15–45 HP [1]")
Delivery date: 20
Product Code:
10000422
Do you need help?
0369 630 012
- Description
- Characteristics
- Reviews (0)
- FAQ
The package includes:
- 1x HADES TA250 PRO clutch with independent oil pump
- 1x BTAM30 digging bucket
Advantages and features
- Autonomous hydraulic system with pump and oil tank .
- Easy operation via two four-motion levers.
- Boom lock for easy and safe transport.
- Two safety legs, hydraulically independent for maximum stability.
- The main joints are made of highly hardened steel.
- Seat with seat belt.
- Boom rotation radius 180 degrees.
- Bucket opening angle up to 203 degrees.
- Reinforced at all stress points.
- The TA250 PRO model has a mechanical boom offset of 700mm with locking.
- International three-point hitch – Category I-II (ø 19.0-22.0mm / 25.0-28.0mm).
- European CE safety certificate.
*Price includes T4-60 PTO shaft with plastic cover and safety screw*
Technical Specifications
Technical Specifications
| Weight | 308 kg |
| Horses | 15 – 45 HP |
| A | 1690mm |
| B | 950mm |
| C | 2280mm |
| D | 2440mm |
| Bucket digging force | 312 kg |
Greutate: 310 kg
Adancime Excavare Maxima: 950 mm
Necesar putere tractor: 15 - 45 CP
If you want to express your opinion about this product you can add a review.
write a review
Does it have its own hydraulic system?
Yes, the model is equipped with its own hydraulic pump and hydraulic oil tank.
Is the digging bucket included?
Yes, the BTAM30 digging bucket is included in the package.
Does the boom allow side shift movement?
Yes, the model features a 700 mm mechanical side shift with locking system.
What is the boom rotation angle?
The boom provides a 180° rotation angle.
Is the PTO shaft included?
Yes, the machine includes a T4-60 PTO shaft with safety guard and shear bolt.
